Барабаны неприводные
|
Характеристики барабанов обводных (отклоняющих, неприводных) |
|||||||||
|
|
|
|
|
|
|
|
|||
|
Ширина ленты В, мм |
Типоразмер барабана |
Допустимая нагрузка Sб, даН |
Условное обозначение подшипника |
Размеры, мм |
Масса, кг |
Чертеж |
|||
|
D |
A |
L |
L1 |
||||||
|
400 |
4024.5-40 (БО.245.500.730.3508) |
400 |
3508 |
245 |
730 |
500 |
806 |
60 |
 |
|
4024.5-40 (БО.245.500.730.3608) |
800 |
3608 |
816 |
65 |
|
||||
|
4024.5-50 (БО.245.500.730.3510) |
1000 |
3510 |
806 |
69 |
 |
||||
|
4024.5-50 (БО.245.500.730.3610) |
1900 |
3610 |
832 |
83 |
|
||||
|
4027.3-40 (БО.273.500.730.3508) |
400 |
3508 |
273 |
806 |
65 |
|
|||
|
4027.3-40 (БО.273.500.730.3608) |
800 |
3608 |
816 |
69 |
|
||||
|
4027.3-40 (БО.273.500.730.3510) |
1000 |
3510 |
806 |
73 |
|
||||
|
4027.3-50 (БО.273.500.730.3610) |
1900 |
3610 |
832 |
87 |
|
||||
|
4032.5-50 (БО.325.500.730.3510) |
1000 |
3510 |
325 |
806 |
89 |
|
|||
|
4032.5-50 (БО.325.500.730.3610) |
1900 |
3610 |
832 |
103 |
|
||||
|
4032.5-60 (БО.325.500.730.3512) |
2100 |
3512 |
822 |
111 |
|
||||
|
4032.5-60 (БО.325.500.730.3612) |
3750 |
3612 |
842 |
127 |
|
||||
|
4040-50 (БО.400.500.730.3510) |
1000 |
3510 |
400 |
806 |
119 |
|
|||
|
4040-50 (БО.400.500.730.3610) |
1900 |
3610 |
832 |
133 |
|
||||
|
4040-60 (БО.400.500.730.3512) |
2100 |
3512 |
822 |
143 |
|
||||
|
4040-60 (БО.400.500.730.3612) |
3750 |
3612 |
842 |
159
|
|
||||
|
4050-60 (БО.500.500.730.3512) |
2100 |
3512 |
500 |
822 |
190 |
|
|||
|
4050-60 (БО.500.500.730.3612) |
3750 |
3612 |
842 |
206 |
|
||||
|
500 |
5024.5-40 (БО.245.600.850.3508) |
400 |
3508 |
245 |
850 |
600 |
926 |
68 |
 |
|
5024.5-40 (БО.245.600.850.3608) |
800 |
3608 |
936 |
73 |
|
||||
|
5024.5-50 (БО.245.600.850.3510) |
1000 |
3510 |
926 |
78 |
|
||||
|
5024.5-50 (БО.245.600.850.3610) |
1900 |
3610 |
952 |
92 |
|
||||
|
5027.3-40 (БО.273.600.850.3508) |
400 |
3508 |
273 |
926 |
73 |
|
|||
|
5027.3-40 (БО.273.600.850.3608) |
800 |
3608 |
936 |
78 |
|
||||
|
5027.3-40 (БО.273.600.850.3510) |
1000 |
3510 |
926 |
83 |
|
||||
|
5027.3-50 (БО.273.600.850.3610) |
1900 |
3610 |
952 |
97 |
|
||||
|
5032.5-50 (БО.325.600.850.3510) |
1000 |
3510 |
325 |
926 |
101 |
|
|||
|
5032.5-50 (БО.325.600.850.3610) |
1900 |
3610 |
952 |
115 |
|
||||
|
5032.5-60 (БО.325.600.850.3512) |
2100 |
3512 |
942 |
125 |
|
||||
|
5032.5-60 (БО.325.600.850.3612) |
3750 |
3612 |
962 |
140 |
|
||||
|
5040-50 (БО.400.600.850.3510) |
1000 |
3510 |
400 |
926 |
135 |
|
|||
|
5040-50 (БО.400.600.850.3610) |
1900 |
3610 |
952 |
149 |
|
||||
|
5040-60 (БО.400.600.850.3512) |
2100 |
3512 |
942 |
160 |
|
||||
|
5040-60 (БО.400.600.850.3612) |
3750 |
3612 |
962 |
176 |
|
||||
|
5050-60 (БО.500.600.850.3512) |
2100 |
3512 |
500 |
942 |
213 |
|
|||
|
5050-60 (БО.500.600.850.3612) |
3750 |
3612 |
962 |
228 |
 |
||||
|
5050-80 (БО.500.600.850.3516) |
2900 |
3516 |
950 |
256 |
|
||||
|
5050-80 (БО.500.600.850.3616) |
5200 |
3616 |
985 |
296 |
|
||||
|
650 |
6524.5-40 (БО.245.750.1000.3508) |
400 |
3508 |
245 |
1000 |
750 |
1076 |
80 |
 |
|
6524.5-40 (БО.245.750.1000.3608) |
800 |
3608 |
1086 |
84 |
|
||||
|
6524.5-50 (БО.245.750.1000.3510) |
1000 |
3510 |
1076 |
90 |
|
||||
|
6524.5-50 (БО.245.750.1000.3610) |
1900 |
3610 |
1102 |
105 |
|
||||
|
6527.3-40 (БО.273.750.1000.3508) |
400 |
3508 |
273 |
1076 |
85 |
|
|||
|
6527.3-40 (БО.273.750.1000.3608) |
800 |
3608 |
1086 |
90 |
|
||||
|
6527.3-50 (БО.273.750.1000.3510) |
1000 |
3510 |
1076 |
96 |
|
||||
|
6527.3-50 (БО.273.750.1000.3610) |
1900 |
3610 |
1102 |
111 |
|
||||
|
6532.5-50 (БО.325.750.1000.3510) |
1000 |
3510 |
325 |
1076 |
118 |
|
|||
|
6532.5-50 (БО.325.750.1000.3610) |
1900 |
3610 |
1102 |
133 |
|
||||
|
6532.5-60 (БО.325.750.1000.3512) |
2100 |
3512 |
1092 |
144 |
|
||||
|
6532.5-60 (БО.325.750.1000.3612) |
3750 |
3612 |
1112 |
159 |
|
||||
|
6540-50 (БО.400.750.1000.3510) |
1000 |
3510 |
400 |
1076 |
158 |
|
|||
|
6540-50 (БО.400.750.1000.3610) |
1900 |
3610 |
1102 |
172 |
|
||||
|
6540-60 (БО.400.750.1000.3512) |
2100 |
3512 |
1092 |
185 |
|
||||
|
6540-60 (БО.400.750.1000.3612) |
3750 |
3612 |
1112 |
200 |
|
||||
|
6550-60 (БО.500.750.1000.3512) |
2100 |
3512 |
500 |
1092 |
245 |
|
|||
|
6550-60 (БО.500.750.1000.3612) |
3750 |
3612 |
1112 |
261 |
|
||||
|
6550-80 (БО.500.750.1000.3516) |
2900 |
3516 |
1100 |
292 |
|
||||
|
6550-80 (БО.500.750.1000.3616) |
5200 |
3616 |
1135 |
333 |
|
||||
|
6563-100 (БО.630.750.1000.3520) |
5000 |
3520 |
630 |
1125 |
451 |
 |
|||
|
6563-100 (БО.630.750.1000.3620) |
8000 |
3620 |
1153 |
504 |
|
||||
|
6563-120 (БО.630.750.1000.3524) |
7500 |
3524 |
1138 |
566 |
|
||||
|
6563-120 (БО.630.750.1000.3624) |
12500 |
3624 |
1185 |
679 |
|
||||
|
800 |
8024.5-40 (БО.245.950.1350.3508) |
400 |
3508 |
245 |
1350 |
950 |
1426 |
97 |
 |
|
8024.5-40 (БО.245.950.1350.3608) |
800 |
3608 |
1436 |
103 |
|
||||
|
8024.5-50 (БО.245.950.1350.3510) |
1000 |
3510 |
1426 |
110 |
|
||||
|
8024.5-50 (БО.245.950.1350.3610) |
1900 |
3610 |
1452 |
127 |
|
||||
|
8027.3-40 (БО.273.950.1350.3508) |
400 |
3508 |
273 |
1426 |
104 |
|
|||
|
8027.3-40 (БО.273.950.1350.3608) |
800 |
3608 |
1436 |
109 |
|
||||
|
8027.3-50 (БО.273.950.1350.3510) |
1000 |
3510 |
1426 |
117 |
|
||||
|
8027.3-50 (БО.273.950.1350.3610) |
1900 |
3610 |
1452 |
133 |
|
||||
|
8032.5-50 (БО.325.950.1350.3510) |
1000 |
3510 |
325 |
1426 |
144 |
|
|||
|
8032.5-50 (БО.325.950.1350.3610) |
1900 |
3610 |
1452 |
161 |
|
||||
|
8032.5-60 (БО.325.950.1350.3512) |
2100 |
3512 |
1442 |
173 |
|
||||
|
8032.5-60 (БО.325.950.1350.3612) |
3750 |
3612 |
1462 |
190 |
|
||||
|
8040-50 (БО.400.950.1350.3510) |
1000 |
3510 |
400 |
1426 |
191 |
|
|||
|
8040-50 (БО.400.950.1350.3610) |
1900 |
3610 |
1452 |
207 |
|
||||
|
8040-60 (БО.400.950.1350.3512) |
2100 |
3512 |
1442 |
222 |
|
||||
|
8040-60 (БО.400.950.1350.3612) |
3750 |
3612 |
1462 |
238 |
|
||||
|
8050-60 (БО.500.950.1350.3512) |
2100 |
3512 |
500 |
1442 |
293 |
|
|||
|
8050-60 (БО.500.950.1350.3612) |
3750 |
3612 |
1462 |
309 |
|
||||
|
8050-80 (БО.500.950.1350.3516) |
2900 |
3516 |
1450 |
349 |
|
||||
|
8050-80 (БО.500.950.1350.3616) |
5200 |
3616 |
1485 |
389 |
|
||||
|
8050-100 (БО.500.950.1350.3520) |
5000 |
3520 |
1475 |
430 |
|
||||
|
8050-100 (БО.500.950.1350.3620) |
8000 |
3620 |
1503 |
483 |
 |
||||
|
8063-100 (БО.630.950.1350.3520) |
5000 |
3520 |
630 |
1475 |
526 |
|
|||
|
8063-100 (БО.630.950.1350.3620) |
8000 |
3620 |
1503 |
579 |
|
||||
|
8063-120 (БО.630.950.1350.3524) |
7500 |
3524 |
1488 |
654 |
|
||||
|
8063-120 (БО.630.950.1350.3624) |
12500 |
3624 |
1535 |
766 |
|
||||
|
8063-140 (БО.630.950.1350.3528) |
10500 |
3528 |
1512 |
813 |
|
||||
|
8063-140 (БО.630.950.1350.3628) |
15500 |
3628 |
1558 |
979 |
|
||||
|
8063-160 (БО.630.950.1350.3532) |
11500 |
3532 |
1533 |
953 |
|
||||
|
8063-160 (БО.630.950.1350.3632) |
19000 |
3632 |
1577 |
1189 |
|
||||
|
1000 |
10024.5-40 (БО.245.1150.1580.3508) |
400 |
3508 |
245 |
1580 |
1150 |
1656 |
113 |
 |
|
10024.5-40 (БО.245.1150.1580.3608) |
800 |
3608 |
1666 |
118 |
|
||||
|
10024.5-50 (БО.245.1150.1580.3510) |
1000 |
3510 |
1656 |
128 |
|
||||
|
10024.5-50 (БО.245.1150.1580.3610) |
1900 |
3610 |
1682 |
145 |
|
||||
|
10027.3-40 (БО.273.1150.1580.3508) |
400 |
3508 |
273 |
1656 |
121 |
|
|||
|
10027.3-40 (БО.273.1150.1580.3608) |
800 |
3608 |
1666 |
126 |
|
||||
|
10027.3-50 (БО.273.1150.1580.3510) |
1000 |
3510 |
1656 |
136 |
|
||||
|
10027.3-50 (БО.273.1150.1580.3610) |
1900 |
3610 |
1682 |
153 |
|
||||
|
10032.5-50 (БО.325.1150.1580.3510) |
1000 |
3510 |
325 |
1656 |
168 |
|
|||
|
10032.5-50 (БО.325.1150.1580.3610) |
1900 |
3610 |
1682 |
185 |
|
||||
|
10032.5-60 (БО.325.1150.1580.3512) |
2100 |
3512 |
1672 |
200 |
|
||||
|
10032.5-60 (БО.325.1150.1580.3612) |
3750 |
3612 |
1692 |
216 |
|
||||
|
10040-50 (БО.400.1150.1580.3510) |
1000 |
3510 |
400 |
1656 |
222 |
|
|||
|
10040-50 (БО.400.1150.1580.3610) |
1900 |
3610 |
1682 |
239 |
|
||||
|
10040-60 (БО.400.1150.1580.3512) |
2100 |
3512 |
1672 |
255 |
|
||||
|
10040-60 (БО.400.1150.1580.3612) |
3750 |
3612 |
1692 |
272 |
|
||||
|
10050-60 (БО.500.1150.1580.3512) |
2100 |
3512 |
500 |
1672 |
337 |
|
|||
|
10050-60 (БО.500.1150.1580.3612) |
3750 |
3612 |
1692 |
353 |
|
||||
|
10050-80 (БО.500.1150.1580.3516) |
2900 |
3516 |
1680 |
399 |
|
||||
|
10050-80 (БО.500.1150.1580.3616) |
5200 |
3616 |
1715 |
439 |
|
||||
|
10050-100 (БО.500.1150.1580.3520) |
5000 |
3520 |
1705 |
486 |
|
||||
|
10050-100 (БО.500.1150.1580.3620) |
8000 |
3620 |
1733 |
540 |
|
||||
|
10050-120 (БО.500.1150.1580.3524) |
7500 |
3524 |
1718 |
619 |
|
||||
|
10050-120 (БО.500.1150.1580.3624) |
12500 |
3624 |
1765 |
732 |
|
||||
|
10063-100 (БО.630.1150.1580.3520) |
5000 |
3520 |
630 |
1705 |
591 |
|
|||
|
10063-100 (БО.630.1150.1580.3620) |
8000 |
3620 |
1733 |
644 |
|
||||
|
10063-120 (БО.630.1150.1580.3524) |
7500 |
3524 |
1718 |
727 |
|
||||
|
10063-120 (БО.630.1150.1580.3624) |
12500 |
3624 |
1765 |
840 |
|
||||
|
10063-140 (БО.630.1150.1580.3528) |
10500 |
3528 |
1742 |
895 |
|
||||
|
10063-140 (БО.630.1150.1580.3628) |
15500 |
3628 |
1788 |
1062 |
|
||||
|
10063-160 (БО.630.1150.1580.3532) |
11500 |
3532 |
1763 |
1046 |
 |
||||
|
10063-160 (БО.630.1150.1580.3632) |
19000 |
3632 |
1807 |
1282 |
|
||||
|
10063-170 (БО.630.1150.1580.3534) |
15000 |
3534 |
1771 |
1135 |
|
||||
|
10063-170 (БО.630.1150.1580.3634) |
22000 |
3634 |
1813 |
1409 |
|
||||
|
10063-180 (БО.630.1150.1580.3536) |
16500 |
3536 |
1778 |
1227 |
|
||||
|
10063-180 (БО.630.1150.1580.3636) |
24700 |
3636 |
1819 |
1503 |
|
||||
|
10080-180 (БО.800.1150.1580.3536) |
16500 |
3536 |
800 |
1778 |
1635 |
 |
|||
|
10080-180 (БО.800.1150.1580.3636) |
24700 |
3636 |
1819 |
1912 |
|
||||
|
10080-200 (БО.800.1150.1580.3540) |
25000 |
3540 |
1790 |
1894 |
 |
||||
|
10080-200 (БО.800.1150.1580.3640) |
37500 |
3640 |
1831 |
2239 |
|
||||
|
10080-220 (БО.800.1150.1580.3544) |
30000 |
3544 |
1800 |
2139 |
|
||||
|
10080-220 (БО.800.1150.1580.3644) |
44500 |
3644 |
1838 |
2441 |
|
||||
|
1200 |
12024.5-40 (БО.245.1400.1900.3508) |
400 |
3508 |
245 |
1900 |
1400 |
1976 |
135 |
 |
|
12024.5-40 (БО.245.1400.1900.3608) |
800 |
3608 |
1986 |
141 |
|
||||
|
12024.5-50 (БО.245.1400.1900.3510) |
1000 |
3510 |
1976 |
153 |
|
||||
|
12024.5-50 (БО.245.1400.1900.3610) |
1900 |
3610 |
2002 |
170 |
|
||||
|
12027.3-40 (БО.273.1400.1900.3508) |
400 |
3508 |
273 |
1976 |
145 |
|
|||
|
12027.3-40 (БО.273.1400.1900.3608) |
800 |
3608 |
1986 |
151 |
|
||||
|
12027.3-50 (БО.273.1400.1900.3510) |
1000 |
3510 |
1976 |
163 |
|
||||
|
12027.3-50 (БО.273.1400.1900.3610) |
1900 |
3610 |
2002 |
180 |
|
||||
|
12032.5-50 (БО.325.1400.1900.3510) |
1000 |
3510 |
325 |
1976 |
202 |
|
|||
|
12032.5-50 (БО.325.1400.1900.3610) |
1900 |
3610 |
2002 |
220 |
|
||||
|
12032.5-60 (БО.325.1400.1900.3512) |
2100 |
3512 |
1992 |
237 |
|
||||
|
12032.5-60 (БО.325.1400.1900.3612) |
3750 |
3612 |
2012 |
254 |
|
||||
|
12040-50 (БО.400.1400.1900.3510) |
1000 |
3510 |
400 |
1976 |
270 |
|
|||
|
12040-50 (БО.400.1400.1900.3610) |
1900 |
3610 |
2002 |
287 |
|
||||
|
12040-60 (БО.400.1400.1900.3512) |
2100 |
3512 |
1992 |
306 |
|
||||
|
12040-60 (БО.400.1400.1900.3612) |
3750 |
3612 |
2012 |
323 |
|
||||
|
12050-60 (БО.500.1400.1900.3512) |
2100 |
3512 |
50 |
1992 |
408 |
|
|||
|
12050-60 (БО.500.1400.1900.3612) |
3750 |
3612 |
2012 |
425 |
|
||||
|
12050-80 (БО.500.1400.1900.3516) |
2900 |
3516 |
2000 |
477 |
|
||||
|
12050-80 (БО.500.1400.1900.3616) |
5200 |
3616 |
2035 |
517 |
|
||||
|
12050-100 (БО.500.1400.1900.3520) |
5000 |
3520 |
2025 |
574 |
|
||||
|
12050-100 (БО.500.1400.1900.3620) |
8000 |
3620 |
2053 |
627 |
|
||||
|
12050-120 (БО.500.1400.1900.3524) |
7500 |
3524 |
2038 |
717 |
|
||||
|
12050-120 (БО.500.1400.1900.3624) |
12500 |
3624 |
2085 |
830 |
|
||||
|
12063-100 (БО.630.1400.1900.3520) |
5000 |
3520 |
630 |
2025 |
708 |
|
|||
|
12063-100 (БО.630.1400.1900.3620) |
8000 |
3620 |
2053 |
761 |
|
||||
|
12063-120 (БО.630.1400.1900.3524) |
7500 |
3524 |
2038 |
854 |
|
||||
|
12063-120 (БО.630.1400.1900.3624) |
12500 |
3624 |
2085 |
967 |
|
||||
|
12063-140 (БО.630.1400.1900.3528) |
10500 |
3528 |
2062 |
1034 |
|
||||
|
12063-140 (БО.630.1400.1900.3628) |
15500 |
3628 |
2108 |
1021 |
|
||||
|
12063-160 (БО.630.1400.2000.3532) |
11500 |
3532 |
2083 |
1320 |
|
||||
|
12063-160 (БО.630.1400.1900.3632) |
19000 |
3632 |
2127 |
1434 |
|
||||
|
12063-170 (БО.630.1400.1900.3534) |
15000 |
3534 |
2091 |
1294 |
|
||||
|
12063-170 (БО.630.1400.1900.3634) |
22000 |
3634 |
2133 |
1569 |
|
||||
|
12063-180 (БО.630.1400.1900.3536) |
16500 |
3536 |
2098 |
1394 |
|
||||
|
12063-180 (БО.630.1400.1900.3636) |
24700 |
3636 |
2139 |
1670 |
|
||||
|
12080-180 (БО.800.1400.1900.3536) |
16500 |
3536 |
800 |
2098 |
1878 |
|
|||
|
12080-180 (БО.800.1400.1900.3636) |
24700 |
3636 |
2139 |
2155 |
|
||||
|
12080-200 (БО.800.1400.1900.3540) |
25000 |
3540 |
2110 |
2153 |
|
||||
|
12080-200 (БО.800.1400.1900.3640) |
37500 |
3640 |
2151 |
2497 |
|
||||
|
12080-220 (БО.800.1400.1900.3544) |
30000 |
3544 |
2120 |
2415 |
|
||||
|
12080-220 (БО.800.1400.1900.3644) |
44500 |
3644 |
2158 |
2717 |
|
||||
|
1400 |
14040-50 (БО.400.1600.2000.3510) |
1000 |
3510 |
400 |
2000 |
1600 |
2076 |
298 |
|
|
14040-50 (БО.400.1600.2000.3610) |
1900 |
3610 |
2102 |
315 |
|
||||
|
14040-60 (БО.400.1600.2000.3512) |
2100 |
3512 |
2092 |
336 |
|
||||
|
14040-60 (БО.400.1600.2000.3612) |
3750 |
3612 |
2112 |
352 |
|
||||
|
14050-60 (БО.500.1600.2000.3512) |
2900 |
3512 |
500 |
2092 |
448 |
|
|||
|
14050-60 (БО.500.1600.2000.3612) |
5200 |
3612 |
2112 |
465 |
|
||||
|
14050-80 (БО.500.1600.2000.3516) |
5000 |
3516 |
2100 |
520 |
|
||||
|
14050-80 (БО.500.1600.2000.3616) |
8000 |
3616 |
2135 |
560 |
|
||||
|
14050-100 (БО.500.1600.2000.3520) |
7500 |
3520 |
2125 |
620 |
|
||||
|
14050-100 (БО.500.1600.2000.3620) |
12500 |
3620 |
2153 |
673 |
|
||||
|
14050-120 (БО.500.1600.2000.3524) |
7500 |
3524 |
2138 |
766 |
|
||||
|
14050-120 (БО.500.1600.2000.3624) |
12500 |
3624 |
2185 |
878 |
|
||||
|
14063-100 (БО.630.1600.2000.3520) |
5000 |
3520 |
630 |
2125 |
815 |
|
|||
|
14063-100 (БО.630.1600.2000.3620) |
8000 |
3620 |
2153 |
868 |
|
||||
|
14063-120 (БО.630.1600.2000.3524) |
7500 |
3524 |
2138 |
966 |
|
||||
|
14063-120 (БО.630.1600.2000.3624) |
12500 |
3624 |
2185 |
1079 |
|
||||
|
14063-140 (БО.630.1600.2000.3528) |
10500 |
3528 |
2162 |
1152 |
|
||||
|
14063-140 (БО.630.1600.2000.3628) |
15500 |
3628 |
2208 |
1318 |
|
||||
|
14063-160 (БО.630.1600.2000.3532) |
11500 |
3532 |
2183 |
1320 |
|
||||
|
14063-160 (БО.630.1600.2000.3632) |
19000 |
3632 |
2227 |
1556 |
|
||||
|
14063-170 (БО.630.1600.2000.3534) |
15000 |
3534 |
2191 |
1419 |
|
||||
|
14063-170 (БО.630.1600.2000.3634) |
22000 |
3634 |
2233 |
1693 |
|
||||
|
14063-180 (БО.630.1600.2000.3536) |
16500 |
3536 |
2198 |
1520 |
|
||||
|
14063-180 (БО.630.1600.2000.3636) |
24700 |
3636 |
2239 |
1796 |
|
||||
|
14080-180 (БО.800.1600.2000.3536) |
16500 |
3536 |
800 |
2198 |
1984 |
|
|||
|
14080-180 (БО.800.1600.2000.3636) |
24700 |
3636 |
2239 |
2261 |
|
||||
|
14080-200 (БО.800.1600.2000.3540) |
25000 |
3540 |
2210 |
2265 |
|
||||
|
14080-200 (БО.800.1600.2000.3640) |
37500 |
3640 |
2251 |
2609 |
|
||||
|
14080-220 (БО.800.1600.2000.3544) |
30000 |
3544 |
2220 |
2533 |
|
||||
|
14080-220 (БО.800.1600.2000.3644) |
44500 |
3644 |
2258 |
2835 |
|
||||
|
1600 |
16050-60 (БО.500.1800.2200.3512) |
2100 |
3512 |
500 |
2200 |
1800 |
2292 |
491 |
|
|
16050-60 (БО.500.1800.2200.3612) |
3750 |
3612 |
2312 |
508 |
|
||||
|
16050-80 (БО.500.1800.2200.3516) |
2900 |
3516 |
2300 |
568 |
|
||||
|
16050-80 (БО.500.1800.2200.3616) |
5200 |
3616 |
2335 |
608 |
|
||||
|
16050-100 (БО.500.1800.2200.3520) |
5000 |
3520 |
2325 |
674 |
|
||||
|
16050-100 (БО.500.1800.2200.3620) |
8000 |
3620 |
2353 |
727 |
|
||||
|
16050-120 (БО.500.1860.2200.3524) |
7500 |
3524 |
2338 |
826 |
|
||||
|
16050-120 (БО.500.1800.2200.3624) |
12500 |
3624 |
2385 |
939 |
|
||||
|
16063-100 (БО.630.1800.2200.3520) |
5000 |
3520 |
630 |
2325 |
878 |
|
|||
|
16063-100 (БО.630.1800.2200.3620) |
8000 |
3620 |
2353 |
931 |
|
||||
|
16063-120 (БО.630.1800.2200.3524) |
7500 |
3524 |
2338 |
1036 |
|
||||
|
16063-120 (БО.630.1800.2200.3624) |
12500 |
3624 |
2385 |
1149 |
|
||||
|
16063-140 (БО.630.1800.2200.3528) |
10500 |
3528 |
2362 |
1230 |
|
||||
|
16063-140 (БО.630.1800.2200.3628) |
15500 |
3628 |
2408 |
1396 |
|
||||
|
16063-160 (БО.630.1800.2200.3532) |
11500 |
3532 |
2383 |
1406 |
|
||||
|
16063-160 (БО.630.1800.2200.3632) |
19000 |
3632 |
2427 |
1642 |
|
||||
|
16063-170 (БО.630.1800.2200.3534) |
15000 |
3534 |
2391 |
1510 |
|
||||
|
16063-170 (БО.630.1800.2200.3634) |
22000 |
3634 |
2433 |
1784 |
|
||||
|
16063-180 (БО.630.1800.2200.3536) |
16500 |
3536 |
2398 |
1616 |
|
||||
|
16063-180 (БО.630.1800.2200.3636) |
24700 |
3636 |
2439 |
1892 |
|
||||
|
16080-180 (БО.800.1800.2200.3536) |
16500 |
3536 |
800 |
2398 |
2115 |
|
|||
|
16080-180 (БО.800.1800.2200.3636) |
24700 |
3636 |
2439 |
2391 |
|
||||
|
16080-200 (БО.800.1800.2200.3540) |
25000 |
3540 |
2410 |
2406 |
 |
||||
|
16080-200 (БО.800.1800.2200.3640) |
37500 |
3640 |
2451 |
2750 |
|
||||
|
16080-220 (БО.800.1800.2200.3544) |
30000 |
3544 |
2420 |
2685 |
|
||||
|
16080-220 (БО.800.1800.2200.3644) |
44500 |
3644 |
2458 |
2988 |
|
||||
|
Условное обозначение подшипника |
Размеры, мм |
|||||||||
|
dп |
а |
е |
е1 |
h |
h1 |
h2 |
S |
m |
dб |
|
|
3608 |
40 |
175 |
220 |
54 |
70 |
28 |
152 |
19 |
25 |
М16 |
|
3610 |
50 |
210 |
270 |
58 |
85 |
32 |
181 |
24 |
32 |
М20 |
|
3612 |
60 |
240 |
295 |
66 |
100 |
38 |
211 |
24 |
32 |
М20 |
|
3616 |
80 |
300 |
365 |
96 |
130 |
47 |
258 |
28 |
36 |
М24 |
|
3620 |
100 |
365 |
445 |
120 |
155 |
53 |
313 |
35 |
45 |
М30 |
Примечание: dп – диаметр шейки вала под подшипник; dб – диаметр крепежного болта.
Остались вопросы? Спросите у нас!
Отправить сообщение-
Весы промышленные
Тензорезисторы -
Тензодатчики
Комплектующие конвейеров -
Дозаторы весовые
ПитателиЗатворыУзлы встройки
Контрольно-измерительное оборудованиеКонтрольно-измерительное оборудование Контрольно-измерительное оборудование Контрольно-измерительное оборудование
Силоизмерительное оборудованиеКонвейеры ленточныеОборудование для шахт
